12 pump series · made and tested in Mumbai

Pumps

Chemical process pumps machined, assembled and tested in Malad, Mumbai: for acids, hot liquids, liquids that must not leak, tanks and pits, and liquid ammonia.

PP and UHMW-PE centrifugal pump
Moulded plastic casing for acids, pickling and effluent.
Max flow
300 m³/h
Max head
80 m
Temp.
Up to 85 °C
PVDF and PTFE-lined pump
Lined casing for highly corrosive acids up to 150 °C.
Max flow
150 m³/h
Max head
80 m
Temp.
−60 to 150 °C
Metallic back pull-out pump
Alloy pumps to ISO 2858 and DIN 24256, up to 450 °C.
Max flow
500 m³/h
Max head
200 m
Temp.
Up to 450 °C
Self-priming chamber pump
Primes itself to empty pits, drums and underground tanks.
Max flow
150 m³/h
Max head
100 m
Temp.
−20 to 150 °C
Monoblock pump
Pump and motor on one shaft, for tight spaces.
Max flow
500 m³/h
Max head
100 m
Temp.
−20 to 150 °C
Multistage self-priming pump
Lifts up to 6 m with no foot valve, for solvents and oil.
Max flow
100 m³/h
Max head
200 m
Temp.
Up to 150 °C
Submersible dewatering pump
Runs fully submerged to drain tanks, pits and sumps.
Max flow
200 m³/h
Max head
100 m
Temp.
Up to 150 °C
Vertical sump pump
Hangs in the tank, up to 4.5 m long, with no seal or gland.
Max flow
100 m³/h
Max head
100 m
Temp.
−20 to 150 °C
Vertical sealless glandless pump
No seal or gland: any seepage flows back to the tank.
Max flow
200 m³/h
Max head
150 m
Temp.
Up to 150 °C
Liquid ammonia pump
Circulates liquid ammonia in cold stores and ice plants.
Max flow
150 m³/h
Max head
15 kg/cm²
Temp.
−60 to −10 °C
Canned motor pump
Motor and pump sealed in one casing, with no shaft seal.
Max flow
100 m³/h
Max head
100 m
Temp.
Up to 150 °C
Magnetic drive sealless pump
Magnet-driven with no shaft seal, for plating and etching.
Max flow
25 m³/h
Max head
30 m
Temp.
Up to 150 °C

Which pump for which liquid

Start from what you are pumping. Pickling acid, a 450 °C process line and liquid ammonia at −60 °C each need a different casing, drive or seal.

Acids and caustic liquids
Plastic or lined casings that acid can’t eat, from pickling lines to plating.
- PP / UHMW-PE centrifugal pump
  Pickling and effluent, to 85 °C
- PVDF / PTFE-lined pump
  Corrosive acids, to 150 °C
- Magnetic drive sealless pump
  Plating, anodising and etching
Hot liquids and high heads
Alloy casings for heat up to 450 °C, and several impellers for heads to 200 m.
- Metallic back pull-out pump
  Alloy casing, to 450 °C, 200 m
- PVDF / PTFE-lined pump
  Process liquids to 150 °C
- Multistage self-priming pump
  Several impellers, to 200 m
Liquids that must not leak
No shaft seal or gland to wear, so toxic or costly liquid stays in the pump.
- Canned motor pump
  Motor sealed inside the casing
- Magnetic drive sealless pump
  Magnet drive, no shaft seal
- Vertical glandless pump
  Seepage flows back to the tank
- Vertical sump pump
  Optional seal holds fumes in
Liquid ammonia circulation
Liquid ammonia down to −60 °C, for cold stores, ice plants and food plants.
- Liquid ammonia pump
  Cold stores and ice plants
- Canned motor pump
  Sealless ammonia recirculation
Unloading drums and tanks
Lift liquid out of barrels, drums and underground tanks, with no foot valve.
- Self-priming chamber pump
  Stays primed between runs
- Multistage self-priming pump
  Lifts from 6 m below the pump
- Vertical glandless pump
  Underground tanks, no seal
Pits, sumps and effluent
Pumps that run submerged or hang into the tank, for effluent, sewage and sumps.
- Submersible dewatering pump
  Drains to the lowest level
- Vertical sump pump
  Hangs up to 4.5 m into the tank

Between two pumps, or not on the list? Send us the liquid, its temperature and the flow, and we’ll name the pump.

Pump catalogues to download

Operating ranges, materials and sectional drawings for each series, as PDFs to print or forward to your purchase team.

PDF · 12 pages · 5.3 MB
Industrial pumps
Ten series, each with its operating range, materials, uses and a sectional drawing.
PDF · 4 pages · 2.3 MB
Liquid ammonia pump
The AGP series for cold stores and ice plants: design, advantages and applications.
PDF · 4 pages · 2.3 MB
Multistage pump
The LMSP self-priming series: suction lift, operating range and applications.

All catalogues, including mechanical seals
